| Air flow at 1 speed - extractor by EN 61591 430 m3/h |
Air flow at 2 speed - extractor by EN 61591 540 m3/h |
Air flow at 3 speed - extractor by EN 61591 642 m3/h |
| Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 642 m3/h |
Air Flow at Minimum Speed in Normal Use 430 m3/h |
Air Flow Rate at Best Efficiency Point - Q BEP 396 m3/h |
| Air Pressure at Best Efficiency Point P BEP 340.5 Pa |
Consum energetic anual 78 kWh |
Consum energetic anual estimat 78 kWh |
| Average Illumination of the Lighting System on the Cooking Surface - E middle 87 lux |
Container qty 40'HQ 334 |
Control panel on one side/two sides One side |
| Country of Origin on Rating Label Made in PRC |
Dimensions of grease filter 278,5 x 211 mm |
Display color Red |
| Distance from light cover to wall 385 mm |
Distance to electric hob 450 mm |
Distance to gas hob 650 mm |
| Electric Power Input at Best Efficiency Point - W BEP 173.1 W |
Eficienţa dinamicii fluidelor 21.6 |
Eficienţa dinamicii fluidelor C |
| Grease Filtering Efficiency - GFE hood 82.7 % |
Eficienţă de filtrare a grăsimilor C |
Internal/external motor Internal |
Main lighting colour temperature [K] 6500 |
Iluminare 29 lux/W |
Clasa de eficienţă a iluminării A |
Iluminare A |
Maximum Possible Air Flow 642 m3/h |
Motor unit rated power 230 W |
Motor type/model E series |
Net depth 500 mm |
Net height max 915 mm |
Net height min 535 mm |
Greutate netă 13.3 kg |
Net width 900 mm |
Nivel de zgomot 57 dB |
Nivel de zgomot 63 dB |
Nivel de zgomot 68 dB |
Nominal Power of the Lighting System - W L 3 W |
Number of motor units 1 |
Number units of main lighting 2 |
Diametru canal de evacuare a aerului 150 mm |
Type of plug or cable Euro plug |
Power Consumption in Off Mode - Po 0.34 W |
Power cabel length 120 cm |
Power rating 234 W |
Tensiune de alimentare 230V |
Power unit of main lighting 2 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 68 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 57 dB |
Nivel de zgomot 68 dB |
Time Increase Factor - f 1.2 |
Type of main lighting LED - other |
